Underfloor circularly polarised ultra-low profile antenna

About

The SlimLine A6590C is an ultra-low profile circularly polarised antenna with a convenient doorway-sized footprint. Designed for underfloor mounting, this antenna has a footprint perfect for transforming a standard doorway into an intelligent access point.

Key Benefits:

  • Underfloor mountable - discreet
  • High-gain, constrained beam for localised reads

In retail settings for presence awareness, monitoring conference attendees, or doorway access point monitoring the A6590C is an ideal choice.

Specifications

Dimensions
915 x 305 x 8mm
Frequency Range
902-928MHz (FCC); 865-868MHz (ETSI)
Polarisation
Circularly polarised
Gain
9 dBiC
Beamwidth
20° in XZ-plane, 80° in YZ-plane
Environmental Rating
IP65
Connector Type
SMA

Downloads

A6590C_Datasheet
.pdf
440 KB
STEP File
A6590C_STEP File 19 3 25
.step
780 KB
